PASS QUEST 2X 110BCD (5-bolt AERO) AXS Sprocket Road/ Gravel/Foldable bike

PASS QUEST 2X CHAINRING

• Important Notes:
•
• 110-5BCD is made of a whole aluminum plate by CNC millingThe back is hollowed out and chamfered to ensure strengthwhile reducing the weight of the chainring. The chainringadopts an extended tooth shape, so even if the chain jumpsviolently, it is difficult to get out of the teeth,so as to prevent the chain from falling off.
• For Sram Red Rival S350 S900 Rotor Force 110 BCD 5 Bolts
• Anodized Surface: 7075 aluminum alloy is difficult to anode.For this reason,we through many product proofing.Upgrade sandblasting anode to matte anode.Upgrade sandblasting anode to matte anode.More beautiful texture.
• Lengthened tooth design:Our tooth height is 8.5mm.The teeth extend far beyond the chain.Whenyou jumplike crazy.The chain jerked too hard to get out of thet eeth.So as to truly achieve the chain.
• Countersunk Structure:Maximize the contant area between the screw and the gear plate. Simpler installation effect. Effectively reduce abnormal noise.
• Chainring Strength: The chainring is CNC-made from high-strength7075-T651 aluminum.Triangular and textured structure ensures chainring rigidity.Use force directly.
• The double chainrings are designed well. Do not mix different brands and different gear numbers. Smooth speed change cannot be guaranteed.
• All PASS QUEST double chainring must be used as pass quest original pair set. Mix with other brand chainring will not work.
• We provide standard screws free of charge.
  Locking torque: 6-8 N·M
  Excessive torque may damage the screw
• Installation Instructions:
  1. Position the large chainring pin directly beneath the crank arm.
  2. Align the positioning point on the small chainring directly beneath the crank arm.
  3. Align the countersunk holes with the chainring bolts to complete the installation.
•
